Classification of stainless steel flanges

Stainless steel flanges can be classified according to their structural form and use, and the common classification is as follows:

Classification by structural form:

Butt welded flange: flange and pipe through butt welded connection, high connection strength, suitable for high pressure, high temperature conditions.

Bolted connection flange: flange fixed connection through bolts, common standards are ANSI, DIN, JIS, etc., suitable for general working conditions.

Forged flange: Flange is made by forging processing, with higher strength and durability, suitable for high strength requirements of the working conditions.

Classification by use:

Blind flange: used to block the interface of the pipe or container to prevent media leakage.

Cantilever flange: used to support the weight of pipes or equipment, with strong load capacity.

Butt flanges: used for pipe connection, common welding butt flanges and threaded butt flanges.

Socket flange: used to connect pipes or equipment of different diameters through socket connection.

Classification by connection standard:

ANSI flanges: Flanges manufactured in accordance with the American National Standards Institute (ANSI) standards, commonly ANSI B16.5 and ANSI B16.47.

DIN flanges: Flanges manufactured according to the German standard (DIN), common ones are DIN 2527, DIN 2573 and DIN 2633.

JIS flanges: Flanges manufactured in accordance with Japanese industrial standards (JIS), commonly JIS B2220 and JIS B2210.

The above is a brief introduction to the classification of stainless steel flanges, and the actual application will be selected according to the specific engineering requirements and standards. Different types of stainless steel flanges have different characteristics and scope of application, and need to be selected and used according to the actual situation.
